About Ducab Power Plus Medium Voltage Cables for Oil, Gas and Petrochemical Industries
Ducab Power Plus Medium Voltage Cables for Oil, Gas and Petrochemical Industries
Lead Sheathed Cables
Underground cables in oil, gas and petrochemical industries, in dry and wet regions.
Designed to facilitate land-based activities in the oil, gas, petroleum and chemical industries where the spillage or seepage of corrosive liquids and vapours pose a threat to cables.
TYPE TESTED AND CERTIFIED BY
KEMA and ESMA
BS 6622, IEC 60502-2 & EEMUA 133
Single core copper/aluminium conductor with lead sheathing from 50mm˛ to 1000 mm˛
Three core cables with copper/aluminium conductor with lead sheathing from 50mm˛ to 400mm˛
The lead sheath provided in these cables performs the mechanical function of acting as a barrier to entry of Hydrocarbons.
The lead sheath of the cables can also be engaged to perform the electrical function of sharing the earth fault current with the armour
Lead Sheath also protects cables against radial moisture ingress.
