About Sauna Rooms, Sauna Heaters, Steam Rooms and Steam Generators
Sauna Rooms, Sauna Heaters, Steam Rooms and Steam Generators
STANDARD SAUNA ROOMS
SAUNA HEATER
- Model 1 - Nordia Sauna Heater
- Nordia Sauna Heater with intelligent digital controller.
- Two sets of independent contacts for the thermostatic control and the thermal cut out.
- Temperature setting 50-110°C or 122-230°F.
- Intelligent Sequential heating system, Double over heat protection system for both sauna room and sauna heater.
- Setting time from 0-12 hours.
- Working time: 30 minutes to 12 hours.
- LED diagnostic system.
- Available in 3kW, 4kW,4.5kW, 6kW, 8kW and 9kW.
- Model 2 - Zelma Sauna Heater
- Zelma heavy duty Sauna Heater with stainless steel jacket, intelligent controller and separate control box.
- Two sets of independent contacts for the thermostatic control and the thermal cut out.
- Temperature setting 50-110°C or 122-230°F.
- Intelligent Sequential heating system, double over heat protection system for both sauna room and sauna heater.
- LED diagnostic system, comply with the new CE standard.
- Available in 9KW, 10.5KW,12kW, 14.1kW, 16.2kW, 18kW and 20.1kW
STEAM ROOMS
- Comprises seats full height glass door and its frame.
- Supplied complete with an intelligent steam generator having electronic control with digital display, inlet nozzle and auto drain down and self-flushing function.
- Parts are constructed from extra strong fiberglass reinforced MPC to ensure an extended and trouble free service.
- Sizes can be custom made according to required dimensions, please refer to your AQUA dealer for further details
STEAM GENERATOR
- A new generation steam generator with a host of advanced features.
- An extra heavy duty and robust steam generator manufactured using top quality teflon coated incalloy elements that resist scaling combined with additional electronics for a long trouble free working life.
- All generators feature an advanced electronic control with on board diagnostics having a series of LEDs to show each operation of the boiler. The generator is fitted with several heating elements that operate sequentially, from cold both elements operate for rapid heating, when the steam room temperature is almost reached a number of the elements drops out, and the required temperature is achieved and maintained by the other elements alternating on and off to gently maintain them temperature without large fluctuations improving user comfort.
- All generators feature an auto drain down with a self-flushing cycle to dump the boiler contents in a controlled manner - at the end of each steaming session the generator will stop for a few minutes to allow the water to cool a little then the drain valve will open and after a short time the cold water inlet valve will open to give a period of continuous flushing and draining. Flushing and draining the boiler reduces the buildup of damaging lime scale, cooling the elements before the final drainage helps prolong their useful life.
- Electronic controls with a digital display to enable temperatures of 30 to 60 degrees centigrade and time duration 15 to 240 minutes or continual operation with additional keys for a steam room light, keyboard lock, manual drain down etc.
- Steam inlet nozzle with facility for adding essential oils.
- Safety features include boil dry protection, thermal overload safety cut out and pressure relief valve.
- Complete with installation instructions, 12 months guarantee.
- Please note that for the commercial use of steam generators we strongly recommend the use of softened water, to reduce the buildup of lime scale and reduce maintenance, for additional fragrance injection please order an additional essence dosing kit.
- All steam generators comes with the steam inlet, on-demand steam button, Intelligent digital controller & pressure relief valve.
