2003

Composed by:

• 2 side supports, cast iron EN-GJS-500-7 under UNI EN 1563;
• a single seat in the customs of exotic wood (dimensions mm 425x1600) curved in order to trace the profi le of the media;
• back also made of a single plank of wood Iroko (225x1600 mm size) in order to trace the curved profi media;
• basic support in boxes of stainless steel AISI 304 (section 60x30 mm). Alternatively, both sitting and the back can be made of stainless steel AISI 304. The connection between the support and the support is the peculiarity of this functional element decorative: a hinge at the front of the bench, and an elastic in the back, allowing a slight spring to the seat thereby improving comfort.

Ps: product is also available in stainless steel AISI 316L on request.

Finish:

the cast iron parts undergo a treatment of sanding primer immersion in a zinc component, a hand Spray the same primer with zinc phosphate, fi nish powder kiln-dried gray cast iron (a min. 180 micron), the minimum guarantee 2000 hours in salt spray and the parties in are brushed stainless steel, the wood is treated with a coat of stain and finish for external fi nish.

Fixing:

foot on the ground prepared for tassellaggio with screws stainless steel.

Technical parameters:

1600x625x773h overall dimension mm, seat height 420 mm, total weight 70 kg.
