WAGO Corporation’s new connectors for larger terminal blocks

Other News   Subscribe to newsletter

20 Jun 2012

New connectors for larger terminal blocks extend the functionality of WAGO Corporation’s TOPJOB®S 2006, 2010 and 2016 Series Terminal Blocks. More than standard through connections, the TOPJOB®S connectors insert directly into jumper slots to connect sub-assemblies and test circuits, e.g., electric motors. Accommodating conductors 20–10 AWG, the connectors also provide power tap or supply options for testing — ideal for panel and motor OEMs.

Plug. Test. Ship.:
Used as a pre-assembled test plug harness, TOPJOB®S connectors expedite QA testing prior to shipment — no more landing wires on virtually every terminal block. For additional versatility, the modular connectors can be snapped together, creating custom connector strips. Optional accessories that complement the connectors include strain relief plates and spacer modules used for skipping individual blocks within an assembly.

The connectors carry a 30A/300V rating (UL is pending), which enables TOPJOB®S connectors to function as an additional conductor entry point if needed.

The larger connectors join smaller TOPJOB®S connectors for 2001, 2002 and 2004 Series terminal blocks. This diversity provides more TOPJOB®S terminal block applications with greater adaptability and enhanced convenience. Other time-saving accessories include continuous marking strips and easy-to-use push-in jumpers.

WAGO is the leader in spring pressure connection technology that eliminates loose wires resulting from vibration and temperature cycling, while providing highly reliable, corrosion-resistant and maintenance-free connections. Products: DIN-rail, PCB and chassis mount terminal blocks; signal conditioners; the WAGO-I/O-SYSTEM and more.
