About Axor Showerpipe with thermostatic mixer and 2jet overhead shower designed by Front

Axor Showerpipe with thermostatic mixer and 2jet overhead shower designed by Front

Axor Showerpipe with thermostatic mixer and 2jet overhead shower designed by Front

Consists of

  • Axor 1jet hand shower designed by Front
  • Isiflex shower hose 1.60 m
Features
  • overhead shower Raindance Select S 240 2jet
  • shower head size: 279 mm
  • overhead shower angle adjustable
  • spray type: Rain, RainAir
  • convenient diversion via Select button
  • Individually height adjustable shower head with easy-to-use twist lock. Adjustment 300 mm.
  • flow rate RainAir spray (at 0.3 MPa): 16 l/min
  • flow rate Rain spray (at 0.3 MPa): 17 l/min
  • fully chrome-plated spray disc
  • shower arm length: 400 mm
  • swivel shower arm
  • safety lock at 40° C
  • adjustable hot water limitation
  • outlets controlled via turning handle
  • installation type: exposed installation
  • connection dimension DN15
  • connection thread G ½
  • centre distance 150 mm ± 12 mm
  • height-adjustable hand shower holder
  • suitable for continuous flow water heaters with an output of 18 kW
  • scope of supply: wall bar spacer (grey)
