About Resinous Flooring: Kwörtz Flooring

Resinous Flooring: Kwörtz Flooring

Kwörtz flooring system is a seamless decorative resin flooring system consisting of clear, 100% solids epoxy resin filled with a variety of graded quartz, marble or ceramic fillers which can be modified to create the best design mix for ideal performance and appearance. A wide selection of gloss and satin finish coats are available for varying appearance and exposure requirements. The finished flooring system can be textured or smooth as per the specifications. The decorative quartz aggregates are available in a series of pre-blended patterns or solid colors. Custom color blends are available subject to approval, minimum quantity requirements, and lead time for production.

typical uses

  • Airports
  • Animal Areas
    Cage washing
  • Beverage
  • Cafeterias
  • Chemical Processing
  • Clean Rooms
  • Commercial Kitchens
  • Corridors
  • Food
    Preparation Service
  • Hospitals
    Corridors & Lobbies
    Patient Rooms
    Operating Rooms
  • Laboratories
  • Locker Rooms
  • Mechanical Equipment Rooms
  • Pharmaceutical Plants
  • Schools
  • Showers
  • Manufacturing
    Light and Heavy Duty
  • Warehouses

Crack-free installations of Kwörtz flooring system can be achieved when installed in conjunction with a Perdüre FE80 and Perdüre MVT. An integral cove base can be installed in areas requiring seamless wall to floor coating.

Key Considerations:

  • On or below grade installation must have an efficient vapor barrier under the slab
  • Special treatments are necessary where hydrostatic pressure or
    moisture vapor transmission may be present
  • Substrate temperature must be a minimum of 550F
    (low temperature cure system available upon request)
  • Substrate must be free of dirt, waxes, curing agents, and other foreign materials
  • All control joints and expansion joints in the substrate must be revealed with
    the appropriate divider strips in the topping

Kwörtz flooring system can be installed in different thickness and top coated with 100% epoxy resin, Novolac epoxy resin or solvent based polyurethane depending upon the performance requirements and application environments.

Typical Performance Properties
Flammability, ASTM D-635 Self Extinguishing
Adhesive Strength, MIL-D-26413 420 psi
Fungus & Bacteria growth Will not support growth of fungus or bacteria when subjected to mildew and bacteria tests
Hardness, ASTM D-2240 80-84 Shore D
Bond Strength to Concrete, ACI Comm #503, Bulletin 59-43 400 psi (100% concrete failure)
Resistance to elevated temperature, MIL-D-3134F §4.7.4 No slip or flow at required temperature of 1580F
Coefficient of friction, ASTM D-2047 0.80
Water absorption, ASTM D-570 Nil (<0.05%)
Thermal Shock Resistance, ASTM C-884 Passes
Abrasion Resistance, MIL-D-3134F §4.7.3 Withstands 16ft/lb without cracking, delamination or chipping
Compressive Strength, ASTM C-570, 7 days 12,600psi
Tensile Strength, ASTM C-307 2,600psi
Flexural Strength, ASTM C-580 4,300psi
Thermal of Coefficient of Expansion, ASTM C-531 22 X 10-6

Perdüre NE33

Perdüre NE33 is a 100% solids Novolac epoxy coating ideal for harsh chemical and solvent resistant applications. Perdüre NE33 is used as a binder or seal coat where extreme chemical resistant performance is needed. Perdüre NE33 is excellent for secondary containment, solvent storage, pump pads, trenches and other high exposure areas.


  • Low viscosity ideal for trowelled mortar and slurry applications
  • Exhibits excellent resistance to strong acids, alkalis and most industrial chemicals and solvents
  • 100% Solids – low odor during application and curing
  • Can be recoated in 4-6 hours
Viscosity @ 75°F 1000 – 1500 cps Pot Life 20 minutes @
Mixing Ratio 2 parts A to 1 parts B by volume Dry to Touch 4-6 hours @ 75°F
 Solids Content 100% by volume Re-Coat 10–12 hours @ 75°F
Volatile Organic Content 0 Light Traffic 24 hours @ 75°F
Weight Per gallon 11–11.5 pounds per gallon, mixed Full Cure & Maximum Resistance 5 days

Perdüre U50

Perdüre U50 is a two-component, chemical resistant, polyurethane coating.

Perdüre P70

Perdure P70 is a two component, ultra high solids, aliphatic Polyaspartic polyurea designed to provide high gloss, UV stable (non-yellowing) and chemical resistant protection.

Brochures for Resinous Flooring: Kwörtz Flooring

Brochures for Resinous Flooring: Kwörtz Flooring
Preview Description Format Size Open
Duraamen Company Brochure
PDF 3.9 MB Open
Kwörtz Brochure
Kwörtz Flooring System
PDF 4.2 MB Open
