Resinous Flooring: Self Leveling Epoxy

Perdüre SLE & SLE-T

Typical Uses:

• loading docks
• ramps
• chemical plants
• traffic aisles
• battery plants
• plating rooms

Perdüre SLE (self leveling epoxy) & SLE-T (self levelingepoxy trowell grade ) consists of 100% solids epoxy and selectivelygraded aggregates to produce a seamless flooring solution ideallysuited for industrial flooring applications. It is designed to restoreand replace eroded or spalled concrete floors. When sealed, PerdüreSLE & SLE produce a dense, skid inhibiting surface that eliminatesdirt and chemical penetration. The chemical resistance and overallperformance of Perdüre SLE & SLE-T can be increased by usingdifferent epoxy and polyurethane top coats.

Since no two floors are the same, Perdüre SLE & SLE-T systemsare modified to handle various degrees to chemical, impact and thermalshock resistance. It is applied in thickness ranging from one-sixteenthinch to one-fourth inch. Perdüre SLE & SLE-T is appliedas a three-component system of 100% solids epoxy primer, 100% solidsepoxy body coat that is blended with self-leveling filler and apolyurethane or polyaspartic topcoat.

Perdüre SLE System

1/16" to 1/4" thickness

1. Application of Perdüre E02 – 100% solids epoxy primer

2. Application of a blend of self-leveling filler and Perdüre E10

3. Application of

a. Perdüre E20 – 100% solids epoxy bodycoat OR

b. Perdüre NE25 or Perdüre NE30 – 100% solids Novolac epoxy coating
Note: Perdüre NE25 and Perdüre NE30 have different chemical resistance. You will find each products chemical resistence information on the their technical data sheets.

4. Application of Perdüre U50 – solvent based polyurethane top coat

Perdüre SLE-T System

1/8" thickness

1. Application of Perdüre E02 – 100% solids epoxy primer

2. Application of a blend of self-leveling filler and Perdüre E10

3. Application of a blend of broadcast (30# mesh) aggregate and Perdüre E10

4. Application of

a. Perdüre E20 – 100% solids epoxy bodycoat OR

b. Perdüre NE25 or Perdüre NE30 – 100% solids Novolac epoxy coating
Note: Perdüre NE25 and Perdüre NE30 have different chemical resistance. You will find each products chemical resistence information on the their technical data sheets.

5. Application of Perdüre U50 – solvent based polyurethane top coat

Note: The thickness of Perdüre SL_e and PerdüreSL_e(t) system is modified by changing the number of coatsof self-leveling filler and Perdüre E10 or by changing the sizeand/or quantity of the filler in Perdüre E10. Please conferwith Düraamen technical representative to arrive at specificationsfor your project.

Perdüre E02

Perdüre E02 is a 100% solids, moisture tolerant epoxy primerfor concrete and masonry surfaces. It combines the properties ofwater insensitivity with good wetting properties. It provides excellentfilling and sealing properties needed under high performance epoxyfloor coatings on concrete. The moisture tolerance of perdüreE02 allows it to be applied to damp concrete after surface preparation.This includes bonding “old to old” or “new to old” concrete.

advantages

• Low modulus – stress relieving
• Fast cure formulation available for priming under coatings
• Moisture insensitive cure
• Conforms to ASTM C-881 requirements
• Low viscosity-good wetting properties

Perdüre E10

Perdüre E10 is a 100% solids, multipurpose epoxy binder forDüraamen self leveling mortar and quartz systems. This all purposeepoxy resin is characterized as an excellent general purpose materialwith good clarity and color retention. It is essentially odorlessand therefore can be applied in occupied areas.

ADVANTAGES

• Good troweling properties when used with Duraamen self –leveling epoxy mortar and quartz systems
• Excellent color retention when used as a topcoat with Düraamen flooring systems
• Good troweling properties when used in mortar systems
• Low odor for use in occupied areas
• Available in fast cure systems
• USDA approved for food handling applications

Perdüre E20

Perdüre E20 is a 100% solids, pigmented epoxy floor coatingdesigned to provide high gloss, chemical resistant protection. PerdüreE20 should be used wherever a high build, corrosive resistant,protective floor coating is required. It is essentially odorlessand can, therefore, be used in occupied areas. Perdüre E20 providesa smooth, high gloss finish or, in a heavy body form, an orange peel,texture finish.

ADVANTAGES

• Low odor during application and cure
• Zero VOC
• Easy application and clean-up

Perdüre NE25

Perdüre NE25 is a 100% solids epoxy modified with Novolacepoxy floor coating designed to provide high chemical resistant protection. PerdüreNE25 should be used whenever a high build, acid and alkali resistant,protective floor coating is required. It is essentially odorlessand therefore, can be used in occupied areas. Perdüre NE25 providesa smooth, high gloss finish or, in a heavy body form, an orange peel,textured finish. It is used as a finish coating for High PerformanceIndustrial Floor Systems.

ADVANTAGES

• Superior chemical and stain resistance
• Easy of application
• Bonds very well to cool and damp substrates
• Low odor for use in occupied areas (zero-VOC)
• Suitable for immersion and wet process flooring applications

Perdüre NE30

Perdüre NE30 is a 100% solids epoxy novolac coating ideal forsevere chemical and solvent resistant applications. Low viscositymake Perdüre NE30 ideal use as a binder in trowelledmortar and slurry systems where resistance to 98% sulphuric acidor other strong caustics is needed. Perdüre NE30 is excellentfor secondary containment, solvent storage, pump pads, trenches andother high exposure areas.

ADVANTAGES

• Low viscosity ideal for trowelled mortar and slurry applications
• Exhibits excellent resistance to strong acids, alkalis and most industrial chemicals and solvents
• 100% Solids – low odor during application and curing

Perdüre U50

Perdüre U50 is a two-component, chemical resistant, polyurethanecoating.
