NBT/92

Composed by:

• bell made from cast aluminum UNI EN 1706 (Diameter 560 mm, height 440 mm, thickness 3 mm);
• lower structure made entirely of die-cast aluminum UNI EN 1706;
• access to the optical and the electrical compartment by opening compass of the upper structure contains the parable and the plate components, unlockable by 3 captive screws;
• made of super pure aluminum 99.9%;
• possibilities for optimizing performance in connection with the photometric scope, through regulation system position lamp on a slide with preset or selected locations user in a continuous way;

• cover lens made of frosted tempered flat glass high efficiency thickness 5 mm;
• double pole switch;
• porcelain, available connection type E27 or E40 with IMQ;
• Stainless steel screws;
• Class II isolation;
• degree of protection IP 65;
• CE mark (conforms to EU standards);

Finish:

Aluminum parts undergo a treatment for degreasing, phosphating bottom of the zinc phosphate and powder dried in an oven-resistant UV, with a thickness ≥ 150 microns and minimum guarantee of 2,000 hours spent in salt spray.
