Koni

Composed by:

Palo made of galvanized ERW pipe type (Electrically welded for strength) and UNI EN 10025 FE360B dimensional tolerances allowed UNI EN40 / 2 and EN 10051. 3 or 4 mm thick. The pole is equipped with:

• mail slot 132x38 mm to 1.500 mm from the base to centerline for heights up to 6000 mm;
• mail slot 186x45 mm to 1.800 mm from the base to centerline for heights up to 12.000 mm;
• Grounding plate Placed 600 mm from the base to heights up to 6000 mm and 900 mm for other heights;
• for cable entry hole size as the slot terminal block to 350 mm from base to centerline for heights up to 6000 mm and 600 mm for the other heights;
• shrink tubing for in-ground on request.

For steel poles: hot-dip galvanizing According To UNI-EN 40 / 4. Poles for paint: hot dip galvanizing treatment of Degreasing, phosphate coating the bottom of the zinc phosphate, powder coated and dried in an oven or cast iron gray RAL ( minimum thickness 200 microns), 2.000 minimum guarantee hours in salt spray.
CE Certification to European Standard EN40-5 up to Category IV.

Fixing:

By extension to 600/800 mm into the ground or through the flange.

Technical parameters:

5000/12000 mm height.
