About Naos 1
Naos 1
Composed by:
Palo made pipe type ERW galvanized or stainless steel AISI 316 (electrically welded for strength) and UNI EN 10025 FE360B dimensional tolerances allowed UNI EN40 / 2 and EN 10051. 3 or 4 mm thick.
The pole is equipped with:
132x38 slot mail mm to 1,500 mm from the base to centerline for heights up to 6000 mm;
186x45 slot mail mm to 1,800 mm from the base to centerline for heights up to 12,000 mm;
Grounding plate placed 600 mm from the base to heights up to 6000 mm and 900 mm for other heights;
Slot for cable entry size as the slot terminal strip located 350 mm from base to mid-air at heights up to 6000 mm and 600 mm for other heights;
shrink wrap for the part to be buried on request.
Finish:
for steel poles: hot-dip galvanizing according to UNI-EN 40 / 4. For poles painted: hot-dip galvanizing treatment of degreasing, phosphate coating the bottom of the zinc phosphate and finishing powder dried in an oven or cast iron gray RAL (minimum thickness 200 microns), minimum guarantee 2,000 hours in salt spray. Stainless steel: polishing.
Certifications CE European standard EN40-5 up to Category IV.
Fixing:
600/800 mm through extension to the ground or through the flange.
Technical parameters:
5000/12000 mm height.
