110

Product description:

• stem cylindrical section made ​​of cast iron EN-GJL-200 according to UNI EN 1561 (diameter 95 mm, height 1000);
• cylindrical hat made ​​of cast iron EN-GJL-200, located on the barrel system with male - female and fi xed by grains;
• ring in stainless steel AISI 304 (diameter 85 mm, height 30) housed at 800 mm from the ground.

Finish:

the cast iron parts subjected to sand, primer-component zinc immersion, spray a coat of the same primer with zinc phosphate, kiln-dried powder finish, gray cast iron (minimum thickness. 200 microns), warranty minimum 2000 hours of salt spray and the part is satin stainless steel.

Fixing:

The drive is drowned in the concrete columns to 180 mm. Removable what
is placed in a box hidden Fe 360B steel galvanized and secured with a triangular key.

Technical parameters:

total size
190 x 1000 mm diameter,
weighing 26 kg.

Optional:

CAG16103G iron chain and steel chain CAA16201A.
